HEIMEIER

• Threaded connection: M30 x 1.5

• Liquid-filled thermostat

• Stable control behaviour even with small differences (<1K)


• CEN-certified

• Tested according to DIN EN 215

• Housing made of corrosion-resistant, dezincification-free gunmetal, nickel-plated


• Internal thread on both sides

• Max. operating temperature 120 °C

• Housing and ball made of corrosion-resistant gunmetal


• thermostatic valve body for radiators

• Centre distance of the connections 50 mm

• Housing made of corrosion-resistant, dezincification-free gunmetal, nickel-plated


• The required flow rate of the individual heating circuit is set directly on the valve in l/h.
  Integrated flow rate controller in each heating circuit means that the flow rate is never exceeded, even if the neighbouring heating circuits close.


• Primary side: 2 freely rotatable nuts with DN 25 (1") IT, flat sealing

• Manifold: 2 x manual bleed valve DN 15 (1/2"), 2 x filling and bleeding valve DN 20 (3/4“) hose connection


• Shut-off

• Adjustable

• Operated with a hexagonal wrench SW 5


• For radiators with bottom two-point connection e.g. bathroom radiators

• Suitable for angular or straight installation

• The required flow rate of the individual radiators is set directly on the thermostat valve body, hydraulic balancing is achieved with a single rotation


• For mounting all Heimeier thermostat heads on thermostatic valve bodies, see the table

• Thread M30 x 1.5 according to factory standard

• Threaded connection: M30 x 1.5

• Liquid-filled thermostat

• Stable control behaviour even with small differences (<1K)


• No check valve

• Max. operating temperature: 120°

• Internal thread x flange


• Internal thread x flange

• With check valve

• Max. operating temperature: 90°C


• Housing and ball made of corrosion-resistant gunmetal

• Operating pressure: max. 10 bar

• Ball valve with T-grip


• For radiators with bottom two-point connection e.g. bathroom radiators

• Suitable for angular or straight installation

• The required flow rate of the individual radiators is set directly on the thermostat valve body, hydraulic balancing is achieved with a single rotation


• Insert by replacing the red cap in the T-handle of the Globo ball valve

• To compensate different connection dimensions when replacing radiators

• Connection: DN 15 (R ½”) external thread x union nut (for valve)

• Centre distance: 26 mm


• With shut-off and fine control with
  Double cone

• Without stroke limiter

• No change in the pre-sets when opening
  or closing


• Flush-mounted box including frame, cover plate
  and mounting rails

• Cover and thermostatic head white RAL 9016
  Valve housing:

• Made of corrosion-resistant gunmetal


• With external thread DN 20 (3/4”)

• DN 15 (1/2")

• Max. operating temperature 120°C


HEIMEIER S connection G 3/4 x G 3/4to compensate for different centre distancesHEIMEIER S connection G 3/4 x G 3/4to compensate for different centre distances.Centre distance for each S connection 11.5mmBrand: HeimeierModel: nickel plated brassDN 15 ...

• Straight shape, IT

• Housing made of corrosion-resistant, dezincification-free gunmetal, nickel-plated

• With stainless steel spindle and double O-ring seal


• Globo ball valve for flow and return

• With red and blue sealing cap

• DN 20 (3/4“) IT x DN 25 (1“) ET

Use in two pipe pump heating systems with normal temperature variation for allHeimeier thermostat heads, angled form.Perm. operating temp. TB 130°CPerm. op. pressure PB 10 barLow pressure steam 110°/0.5 barClamp coupling copper or precision steel pipes (only with DN 10 - DN 20),black protection ca ...

• For installation in two-pipe heating systems on radiators with a lower two-point connection, e.g. bathroom, design, universal or valve radiators


• Automatic hydraulic balancing thanks to integrated flow regulator, so the flow rate in the radiator is never exceeded even if the neighbouring valves are closed

• The required flow rate of the individual Radiators is set directly on the thermostatic valve body


• For installation in Heating and cooling systems. The complete upper part of the Thermostats can be replaced with the Heimeier mounting device without draining the system.


• Automatic hydraulic balancing thanks to integrated flow controller, so the flow rate in the Radiators is never exceeded even if the neighbouring valves are closed

• The required flow rate of the individual Radiators is set directly on the thermostatic valve body
