- Recirculation mode and supply/exhaust air mode possible
- Hygienic hot water temperatures of up to 65°C possible in heat pump mode
- Optimised use of own electricity possible through integration of Photovoltaics
- PV control contact already integrated in the appliance
- Magnesium anodes provide corrosion protection in the storage tank
- With additional electric heater (1.5 kW)
- High level of operating convenience via the LCD control panel
- Various operating modes selectable: Heat pumps only, electric only or booster function
- CS 5001 DW 200/260 C: With an additional heat exchanger for integrating Solar or other heat generators
- For monovalent operation
| Type | | 200 | 200 C | 260 | 260 C |
| EEK Hot water heater | A+ to F | A+ | A+ | A+ | A+ |
| Heating capacity (A14/W55) | [kW] | 1.53 | 1.53 | 1.43 | 1.43 |
| COP according to EN16147 (A7/W55) | | 3.5 | 3.5 | 3.6 | 3.6 |
| Tap profile | | L | L | XL | XL |
| Power of electric auxiliary heating | [kW] | 1.5 | 1.5 | 1.5 | 1.5 |
| Memory content | [l] | 202 | 194 | 260 | 251 |
| Refrigerant/filling quantity | [--/kg] | R513A / 1.1 | R513A / 1.1 | R513A / 1.1 | R513A / 1.1 |
| Sound power level | [dBA] | 56 | 56 | 56 | 56 |
| Water temperature max. | [°C] | 65 | 65 | 65 | 65 |
| Air flow rate | [m³/h] | 420 | 420 | 420 | 420 |
| Dimensions (ø x H) | [mm] | 630 x 1720 | 630 x 1720 | 630 x 2010 | 630 x 2010 |
| Weight | [kg] | 105 | 121 | 110 | 128 |
| Ref. no. | | 7738340427 | 7738340428 | 7738340429 | 7738340430 |
